4 Ways SMA Female Bulkhead to 4 Ways SMA Male Connector Cable Assembly with Consolidated Quad LMR195 Cable
The SMA cable assembly can use corrugated, flexible, formable or semirigid coaxial cablesuch as 0.81mm, 1.13mm, 1.37mm, 1/4" Superflexible, LMR100, LMR-195, LMR200, LMR-240, LMR400, RG141, RG142, RG174, RG178, RG179, RG180, RG187, RG188, RG196, RG213, RG214, RG223, RG303, RG316, RG393, RG400, RG401, RG402, RG405, RG55, RG58, RG59, RG62, RG8, TFT-402 or Tinned 047 cable; the body of SMA to SMA cable assembly is right angle or straight connectors which is female to female, female to to male or male to male gender. This SMA female to SMA male cable assembly uses a 50ohm straight 4 ways SMA for connector 1 and a 50ohm straight 4 ways SMA for connector 2, Cable is 50ohm consolidated quad LMR195 cable.
Specifications
| ELECTRICAL DATA | |
| Connector 1 Series | 4 Ways SMA |
| Connector 1 Style | Str Female |
| Cable Type | Consolidated Quad LMR195 |
| Connector 2 Series | 4 Ways SMA |
| Connector 2 Style | Str Male |
| Contact Termination | Solder |
| Shield Termination | Crimp |
| Impedance (Ohms) | 50 |
| Low PIM | No |
| Max Frequency | 6GHz |
| Working Temperature | -65°C to +165°C |
| MATERIAL DATA | |
| Body Material |
Brass |
| Body Finish |
Nickel/Ternary alloy/Gold |
| Contact Material |
Phosphor Bronze/Beryllium Copper |
| Contact Finish |
Gold/Silver |
| Insulator Material | PTFE |
Applications
- Used as an RF Test Probe to 6 GHz
- RF PCB board measurements
- Signal injection
