1.0/2.3 Cable Assemblies

1.0-2.3 Male to BNC Female Cable Assembly

75 ohm RF Coaxial DIN 1.0-2.3 Male to BNC Female with RG179 Cable Assembly

1.0-2.3 Cable assembly Features：

Can be combined with 1.0-2.3, or BNC connector;
Broadband performance with low reflection;
Quick connect/disconnect snap-on mating reduces installation time;
Body is straight with male genders.

Brand:
ROHO
Product Origin:
China
Shipping Port:
Shenzhen
Lead Time:
7-17days

Inquiry Now

Product Detail

75 ohm RF Coaxial DIN 1.0-2.3 Male to BNC Female with RG179 Cable Assembly

The DIN 1.0-2.3 cable assembly can use flexible coaxial cable such as RG316、RG179、LMR100; the body of 1.0-2.3 DIN to BNC cable assembly is straight connectors which is plug to female or plug to male gender. This DIN 1.0-2.3 plug to BNC female cable assembly uses a 50ohm straight 1.0-2.3 for connector 1 and a 50ohm straight BNC for connector 2, Cable is a 50ohm flexible RG179.

Specifications

ELECTRICAL DATA
Connector 1 Series	75ohm 1.0-2.3
Connector 1 Style	Str Male
Cable Type	RG179
Connector 2 Series	BNC
Connector 2 Style	Str Female
Contact Termination	Solder
Shield Termination	Crimp
Impedance (Ohms)	50
Low PIM	No
Max Frequency	3 GHz
Working Temperature	-65°C to +165°C
ELECTRICAL DATA
Body Material	Brass
Body Finish	Nickel/Ternary alloy
Contact Material	Phosphor Bronze/Beryllium Copper
Contact Finish	Gold/Silver
Insulator Material	PTFE

Applications

Laboratory RF test
Measurement
Defense, military
Telecom antenna tower component jumper connection
