1.0/2.3 Adaptors

DIN 1.0/2.3 Plug Male to BNC Female RF Coaxial Adaptor

1.0/2.3 adapters Features:

  • Allow to interface 1.0/2.3 connectors with SMA or BNC connectors;
  • Has jack to female, jack to male, plug to female or plug to male gender;
  • Compact design allows for denser connector ;
  • 50ohm with a maximum frequency of 10GHz, 75ohm with a maximum frequency of 4 GHz.
  • Brand:

    ROHO
  • Product Origin:

    China
  • Shipping Port:

    Shenzhen
  • Lead Time:

    7-17days

DIN 1.0/2.3 Plug Male to BNC Female RF Coaxial Adaptor



The DIN 1.0/2.3 Adapter has different DIN 1.0/2.3 to BNC adapter gender, The DIN 1.0/2.3 to BNC adapters has female to female, female to male, male to female or male to male gender. This DIN 1.0/2.3 male to BNC female adapter has a maximum frequency of 300MHz, and is a straight body adapter.



Specifications

ELECTRICAL DATA
Adapter Side 1 Series DIN 1.0/2.3
Adapter Side 1 Style Plug
Adapter Side 2 Series BNC
Adapter Side 2 Style Female
Frequency (Max GHz) 10
Impedance (Ohms) 50
Low PIM NO
Orientation Straight
Temp (Max Degrees Celsius) 165
Temp (Min Degrees Celsius) -65
MATERIAL DATA
Body Material
Brass
Body Finish
Nickel/Ternary alloy
Contact Material
Phosphor Bronze/Beryllium Copper
Contact Finish
Gold/Silver
Insulator Material
PTFE



Applications

  • high data rates for AES Audio
  • SD video
  • HD video
  • 3Gb/s video
  • high density digital broadcast formats
